SPECIFICATIONS
| Model Type Above:gearbox below in（）：round shaft | Output power W | Voltage V | Frequency Hz | Current A | Starting torque mN.m | Rated tourque mN.m | Rated speed r/min | Capacitor μF | |
| Lead Wire Type | Terminal Box Type | ||||||||
| 5IK120GU-AF (5IK120A-AF) | 5IK120GU-AFT (5IK120A-AFT) | 120 | 1ph100 | 50 | 2.1 | 600 | 930 | 1250 | 30 |
| 5IK120GU-AF (5IK120A-AF) | 5IK120GU-AFT (5IK120A-AFT) | 120 | 1ph100 | 60 | 2.5 | 600 | 750 | 1550 | 30 |
| 5IK120GU-EF (5IK120A-EF) | 5IK120GU-EFT (5IK120A-EFT) | 120 | 1ph110 | 60 | 1.65 | 600 | 750 | 1550 | 25 |
| 5IK120GU-EF (5IK120A-EF) | 5IK120GU-EFT (5IK120A-EFT) | 120 | 1ph120 | 60 | 1.8 | 600 | 750 | 1550 | 25 |
| 5IK120GU-CF (5IK120A-CF) | 5IK120GU-CFT (5IK120A-CFT) | 120 | 1ph220 | 50 | 1 | 650 | 930 | 1250 | 7 |
| 5IK120GU-CF (5IK120A-CF) | 5IK120GU-CFT (5IK120A-CFT) | 120 | 1ph230 | 50 | 0.95 | 650 | 930 | 1250 | 7 |
| 5IK120GU-HF (5IK120A-HF) | 5IK120GU-HFT (5IK120A-HFT) | 120 | 1ph220 | 60 | 1 | 600 | 750 | 1550 | 7 |
| 5IK120GU-HF (5IK120A-HF) | 5IK120GU-HFT (5IK120A-HFT) | 120 | 1ph230 | 60 | 0.95 | 600 | 750 | 1550 | 7 |
| 5IK120GU-SF (5IK120A-SF) | 5IK120GU-FFT (5IK120A-FFT) | 120 | 3ph220 | 50 | 0.7 | 1850 | 930 | 1250 | / |
| 5IK120GU-SF (5IK120A-SF) | 5IK120GU-FFT (5IK120A-FFT) | 120 | 3ph220 | 60 | 0.6 | 1600 | 750 | 1550 | / |
Product Display
The ac induction motor has become the most often used motor due to the phenomenal expansion of the ac power system. The ac motor has a more straightforward construction and is simpler to produce than a dc motor because it lacks a commutator, which makes it straightforward to create motors with high speeds, high voltages, huge currents, and enormous capacities. The power of an alternating current motor may vary from a few watts to hundreds of thousands of kilowatts or even a million kilowatts.
Product Feature
Exceptional Torque Characteristics
Our 120W AC Induction Motor with Gear is designed to offer a high torque output, ensuring powerful performance suitable for a range of heavy-duty applications. Its robust construction provides reliable operation even in the most demanding conditions.
Dependable Start/Stop Capability
The instant start/stop feature of this motor provides users with quick and reliable control, enhancing the functionality in varied operational tasks. This is ideal for applications that require consistent power and immediate response.
Stable Performance and Directionality
This AC induction motor delivers steady starting torque and maintains directional stability, essential for precision tasks and applications that depend on accurate directional control.
Quiet Operation
Operating almost silently, the 120W AC Induction Motor with Gear is perfect for noise-sensitive environments, combining quiet efficiency with potent performance, making it a versatile choice for commercial and domestic applications.
Constant Speed Under Load
At the rated frequency, the motor maintains a stable speed that is unaffected by voltage variations, providing a reliable and consistent performance under varying load conditions.
Protection Against Overload
Designed with durability in mind, the motor's windings are protected against damage whether the motor is overwhelmed or comes to an abrupt stop, ensuring a long service life and less downtime for maintenance.
Quality Engineering for Longevity
The 120W AC Induction Motor with Gear is crafted with attention to detail, promising quiet and lasting performance. Its high-quality engineering stands up to continuous use, offering reliability you can trust.
Product Applications
Industrial Machinery
Our AC gear motor is ideal for the rigors of heavy machinery where consistent power and adaptability to varying loads are a necessity. It can withstand demanding industrial environments and provide reliable performance in applications such as conveyor systems, industrial mixers, and heavy-duty equipment.
Robotics
The precision and variability in speed of our AC gear motor make it an excellent choice for robotics. It offers fine control and dependability, enabling precise movement and positioning of robotic components. It is suitable for applications in industrial automation, collaborative robots (cobots), and other robotic systems.
Automotive Applications
Our AC gear motor finds application in the automotive industry, particularly in equipment that requires torque and reverse functionality. It can be used in assembly lines, maintenance platforms, and other automotive machinery where reliable and versatile motor operation is essential.
Agricultural Equipment
Our AC gear motor flawlessly fits into agricultural machinery that demands high torque for processing, harvesting, or material handling. It can power agricultural equipment such as conveyors, grain augers, harvesters, and feed mixers, providing the necessary strength and reliability for agricultural applications.
Home Appliance Manufacturing
With its adaptability and efficiency, our AC gear motor is a prime choice for manufacturers of home appliances. It is suitable for applications in appliances that require quiet operation, durability, and precise control, such as washing machines, dryers, dishwashers, and more.
