SPECIFICATIONS
Electrical Specification
| Manufacturer Part Number | 36BLR65-24-01 |
| Product Type | BLDC Motor |
| Rated Current(A) | 1.09 |
| Rated Power(W) | 20 |
| Rated Speed(rpm) | 3000 |
| Rated Torque(Nm) | 0.064 |
| Rated Voltage(V) | 24 |
| Phase | 3 |
| Poles | 4 |
| Rated Voltage | 24V |
| Rated Speed | 3000±10%RPM |
| Noload Speed | 4200RPM |
| Rated Torque | 0.064Nm(9.1oz.in) |
| Rated Current | 1.09±10%A |
| Noload Current | 0.1A |
| Rated Power | 20W |
| Insulation Class | Class B |
| Insulation Resistance | 100MΩ Min @500VDC |
| Dielectric Strength Test | 500VAC for 1 Minute |
Physical Specification
| Frame Size | Φ36mm |
| Body Length | 65.2mm |
| Shaft Diameter | Φ4mm |
| Shaft Length | 15mm |
| Number of Leads | 8 |
| Lead Length | 300mm |
| Inventory Method | Dedicated Inventory |
| IP Rating | 20 |
| With Gearbox | No |
| Output Shaft Type | O |
| Bearing Type | NMB Ball Bearing, C3 |
| Sensor | Hall Sensor |
| Weight | 0.3kg |
