SPECIFICATIONS
| Motor Type Lead Wire Type |
Output Power W |
Voltage V |
Frequency Hz |
Current A |
Starting Torque mN.m |
Rated Torque mN.M |
Rated Torque r/min |
Capacitor μF |
|
| Pinion Shaft | Round Shaft | ||||||||
| 0IK3GN-B | 0IK3A-B | 3 | 1ph110 | 50 | 0.12 | 5 | 11 | 2500 | 1.5 |
| 0IK3GN-B | 0IK3A-B | 3 | 1ph110 | 60 | 0.13 | 5 | 10 | 3000 | 1.5 |
| 0IK3GN-D | 0IK3A-D | 3 | 1ph220 | 50 | 0.06 | 5 | 11 | 2500 | 0.35 |
| 0IK3GN-D | 0IK3A-D | 3 | 1ph220 | 60 | 0.064 | 5 | 10 | 3000 | 0.35 |
Allowance Torque Unit
| Type Motor/Gearhead |
Gear Ratio | 3 | 3.6 | 5 | 6 | 7.5 | 9 | 12.5 | 15 | 18 | 25 | 30 | 36 | 50 | 60 | |
| Speed r/min |
50Hz | 500 | 417 | 300 | 250 | 200 | 166 | 120 | 100 | 83 | 60 | 50 | 41 | 30 | 25 | |
| 60Hz | 600 | 500 | 360 | 300 | 240 | 200 | 144 | 120 | 100 | 72 | 60 | 50 | 36 | 30 | ||
| 0IK3GN-B 0IK3GN-D |
0GN K | 50Hz | 0.027 | 0.032 | 0.045 | 0.053 | 0.067 | 0.08 | 0.1 | 0.12 | 0.14 | 0.18 | 0.22 | 0.26 | 0.36 | 0.44 |
| 0IK3GN-B 0IK3GN-D |
0GN K | 50Hz | 0.28 | 0.33 | 0.46 | 0.54 | 0.068 | 0.82 | 1.02 | 1.22 | 1.43 | 1.84 | 2.24 | 2.65 | 3.67 | 4.49 |
| 0IK3GN-B 0IK3GN-D |
0GN K | 60Hz | 0.024 | 0.029 | 0.041 | 0.049 | 0.061 | 0.073 | 0.091 | 0.1 | 0.13 | 0.17 | 0.2 | 0.24 | 0.33 | 0.4 |
| 0IK3GN-B 0IK3GN-D |
0GN K | 60Hz | 0.24 | 0.3 | 0.42 | 0.5 | 0.62 | 0.74 | 0.93 | 1.12 | 0.33 | 1.73 | 2.04 | 2.45 | 3.67 | 4.08 |
Product Display
The ac motor has become the most often used motor due to the phenomenal expansion of the ac power system. The ac motor has a more straightforward construction and is simpler to produce than a dc motor because it lacks a commutator, which makes it straightforward to create motors with high speeds, high voltages, huge currents, and enormous capacities. The power of an alternating current motor may vary from a few watts to hundreds of thousands of kilowatts or even a million kilowatts.
Product Feature
High-Quality Engineering
The 3W AC Induction Gear Motor benefits from high-quality engineering, ensuring quiet and prolonged operational performance. Its construction facilitates a maintenance-free long life, making it an ideal choice for continuous use applications.
Outstanding Torque Characteristics
This motor boasts high torque up to 120 RPM with a low starting voltage of 12V, offering exceptional control and power efficiency for various applications.
Instant Start/Stop Functionality
Designed for dynamic applications, the motor provides instant start/stop capabilities without compromising on stability, making it perfect for operations requiring quick response times.
Reliable Starting and Directional Stability
With reliable starting and directional stability, the motor ensures precise and consistent performance under all working conditions.
Near-Silent Operation
The motor operates with near-silence, making it suitable for noise-sensitive environments where operational discretion is a priority.
Consistent Performance Under Rated Frequency
Under the rated frequency, the speed status remains unchanged and unaffected by voltage fluctuations, providing reliable and consistent operation.
Protective Design
The motor's winding remains undamaged, even under overload conditions or in the event of an abrupt stop, ensuring durability and reliability.
Product Applications
Industrial Automation
With its precise control and low noise operation, this motor is ideal for a variety of industrial automation tasks, where consistent performance and minimal disturbance are essential.
Medical Devices
The instant start/stop functionality and silent operation of the motor make it perfect for use in medical devices, where precision and quietness are paramount.
Laboratory Equipment
Its reliability and directional stability make it suitable for laboratory equipment that demands high precision and consistent operation.
Consumer Electronics
This motor is suitable for consumer electronics that require compact size, efficiency, and quiet operation, enhancing the user experience by minimizing operational noise.
Office Automation
With outstanding torque characteristics and protective design, this motor is optimal for office automation equipment, ensuring durability and reliable performance.
Small Scale Renewable Energy Projects
The power efficiency and reliable performance of the motor make it perfect for small scale renewable energy projects where efficient operation is crucial.
